Features:
- Heavy sheet metal frame and base.
- Extra large radial-fin type steel impeller for high efficiency air flow.
- Heavy duty, totally enclosed industrial motor for maximum air suction and extended service life.
- Low sound levels to keep the working area quiet.
Specification:
| SPECIFICATIONS | DC-9100 | DC-9200 | DC-9250 |
| Motor | 10 HP 3 PH | 20 HP 3 PH | 25 HP 3 PH |
| Fan Diameter | 15" | 16" | 16" |
| Static Pressure (INH2O) | 23 | 27 | 27 |
| Air Capacity | 6300 | 7500 | 8300 |
| Sound Rating (db) | 85 ~ 95 | 85 ~ 95 | 85 ~ 95 |
| Connection Outlet Dia. | 10" | 15" | 16" |
| Top Filter Bag Size (Dia x H) | 13.8" x 59" | 13.8" x 59" | 13.8" x 59" |
| Top Filter Bag Quantity | 10 | 20 | 20 |
| Bottom Collect Bag Size | 23.6" x 35.5" | 23.6" x 35.5" | 23.6" x 35.5" |
| Bottom Collect Bag Quantity | 4 | 6 | 6 |
| Machine Size | 138" x 39" x 120" | 181" x 47" x 120" | 181" x 47" x 120" |
| N.W. | 1360 | 1770 | 1960 |
